Éjjellátó készülékek Photonis DEP

ONYX version is equipped with white phosphor P45 and the result is black&white image. This device with image intesifier tube Gen.2+ DEP - Photonis in version Delta ONYX AG has resolution minimal 57 lp/mm, S/N Ratio minimal 24, photocathode sensitivity is classified information and gain between 28 260x - 47 120x. FOM is minimal 1500. Lifetime is minimal 10 000+ hours. This is definitely not DEP 0 or DST version. Real parameters DEP Delta AG are in general much higher against minimal guaranteed parameters DEP 0 and parameters DEP DST too. IIT is Autogated.

Uncompromising performance of the Select Alpha image intensifiers for Generation 2 price. Derived from the highly successful LVLMi-14, G-14 offers high quality, outstanding reliability, and unbeatable value for the most discerning professionals. G -14 features a unique ergonomic design that allows very comfortable single-handed operation and dramatically minimizes the probability of user errors in extreme conditions. The unit operates on one CR-123 battery to keep the weight to a minimum and guarantees reliable service at a wide range of temperatures. The monocular is equipped with an invisible to the human eye short range infrared illuminator to assist with tasks that have to be performed in complete darkness, such as map reading, equipment repairs, etc. G-14 comes standard with Mil Spec headgear, weapon mount, Camera/Video adapter, sacrificial window, and soft carrying case making in it one of the most versatile “out-of-the box” systems on the market. With the use of standard and optional accessories, G-14 can be configured for a multitude of mission requirements:

- Hand held spotting scope (can be used alone, with optional magnification lenses, or attached to a daytime spotting scope with the optional universal adapter)
- Hands free mono-goggle (with the included headgear or optional helmet mount)
- Day/Night weapon sight (with the use of the included weapon mount and optional EoTech/Aimpoint, or attached to an existing rifle scope with the optional universal adapter
- Hand held binocular (with the use of an optional Bridge Assembly and optional magnification lenses)
- Surveillance and night-time photography (with the use of the included camera adapter)


Specifications:

Image Intensifier  Generation 2
Magnification  1x (3x optional)
Lens System  23 mm f1.2
FOV  40° / @1000 yards  2099’ / @1000 meters  640 meters
Range of Focus  10’’ to infinity / 25 cm to infinity
Detection Range   450 meters
Recognition Range  300 meters
Diopter Adjustment  +5 D to -4 D
Weather Resistant  Water Proof 6’ (1,8m) for 120 min
Camera/Camcorder Adaptable  Yes
IR Illuminator  Yes
Battery Type/Life  CR123 (1x) /40 hours
Dimensions  4.5" x 2.6" x 1.9" / 115mm x 66mm x 49mm
Weight  11 oz / 312 grams
Operating Temperature  -22° F to 125° F / -30°C to +52°C


Included:

Soft Carry Case
Mil.Spec. Headgear w/extra Brow Pads
Adapter for Mil.Spec. Headgear/Helmet Mount
Weapon Mount
Sacrificial Window
Camera/Video Adapter
One 3V CR123 Battery


Available Accessories:

3x A-focal Lens
Bridge Assembly
Helmet Mount (requires adapter)
Universal Adapter
ELR IR Illuminator
Shuttered Eyeguard
EOTech 551 "N Cell" HOLOgraphic Weapon Sight
EOTech 552 "AA" HOLOgraphic Weapon Sight
GG&G 1190 AccuCam Quick Detach Locking Lever System for EoTech 551/552
AIMPOINT® Comp M3
A.R.M.S.® #22M68 Throw Lever® Ring
A.R.M.S.® #22M68 Spacer
GG&G 1014 Aimpoint® Cantilever Ring
GG&G 1191 AccuCam Quick Detach Aimpoint® Cantilever Ring
Aimpoint® 3x Magnifier
GG&G 1233 3x Adapter Plate
